Features:
1. Astigmatic design is applied to rugged surroundings
2. Continuously gas concentration and composition colorful LCD real-time display
3. Rechargeable lithium battery (continous working period can be 16-18 hours)
4. Concentration units ppm and mg/m3 can be switched
5. Built-in vibration alarm which is applied for noisy environment
6. Two stage alarm threshold: the low alarm and high alarm point can be adjusted based on actual needs
7. Simple automatic calibration program and plug-in replaceable sensor
8. Fully function self-testing: sensor, integrity of battery and circuit, acounstic & visual & vibration three-stage alarm
9. Small figue and light weight
10. Password protection capacity: Only the authorized users can modify the preset parameter
Specifications:
Sensor | Electrochemical |
Detection gases | Phosphine (PH3) |
Detecting range | 0-20ppm |
Alarm level | 5ppm and 10ppm or Customerized |
Resolution | 0.1ppm |
Time display | Year, month, day, and clock display function |
Alarm ways | voice alarm More than 90 dB (10cm away from instrument), light alarm |
Work mode | continuous work |
Temperature | - 20 ℃ ~ 50 ℃ |
Humidity | 15% ~ 95% RH (No condensation) |
Power supply | lithium battery power supply (1800 mAh) |
Charging time | 3 ~ 5 hours |
Working time | 12h without alarm |
Charging voltage | DC5V |
Model | Range | Resolution | L-alarm | H-alarm |
CO | 0-1000ppm | 1ppm | 50ppm | 150ppm |
O2 | 0-30%vol | 0.1%vol | 19.5%vol | 23.5%vol |
H2 | 0-1000ppm | 1ppm | 50ppm | 150ppm |
H2S | 0-100ppm | 0.1ppm | 10ppm | 20ppm |
CH4 | 0-100%LEL | 1%lel | 20%LEL | 50%LEL |
C2H4O | 0-100ppm | 1/0.1ppm | 20ppm | 50ppm |
EX | 0-100%LEL | 1%lel/1%vol | 20%LEL | 50%LEL |
C3H8 | 0-100%LEL | 1%lel/1%vol | 20%LEL | 50%LEL |
C2H5OH | 0-100%LEL | 1%lel/1%vol | 20%LEL | 50%LEL |
NH3 | 0-100ppm | 0.1/1ppm | 20ppm | 50ppm |
CL2 | 0-20ppm | 0.1ppm | 5ppm | 10ppm |
O3 | 0-10ppm | 0.1ppm | 2ppm | 5ppm |
SO2 | 0-20ppm | 0.1/1ppm | 5ppm | 10ppm |
PH3 | 0-20ppm | 0.1ppm | 5ppm | 10ppm |
CO2 | 0-5000ppm | 1ppm/0.1%vol | 1000ppm | 2000ppm |
NO | 0-250ppm | 1ppm | 50ppm | 150ppm |
NO2 | 0-20ppm | 0.1ppm | 5ppm | 10ppm |
HCN | 0-50ppm | 0.1/0.01ppm | 10ppm | 20ppm |
HCL | 0-20ppm | 0.001/0.1ppm | 5ppm | 10ppm |
CH2O | 0-20ppm | 1/0.1ppm | 5ppm | 10ppm |
HF | 0-100ppm | 0.01/0.1ppm | 2ppm | 5ppm |
C7H8/C8H10 | 0-20ppm | 0.01/0.1ppm | 5ppm | 10ppm |
Features:
1. Astigmatic design is applied to rugged surroundings
2. Continuously gas concentration and composition colorful LCD real-time display
3. Rechargeable lithium battery (continous working period can be 16-18 hours)
4. Concentration units ppm and mg/m3 can be switched
5. Built-in vibration alarm which is applied for noisy environment
6. Two stage alarm threshold: the low alarm and high alarm point can be adjusted based on actual needs
7. Simple automatic calibration program and plug-in replaceable sensor
8. Fully function self-testing: sensor, integrity of battery and circuit, acounstic & visual & vibration three-stage alarm
9. Small figue and light weight
10. Password protection capacity: Only the authorized users can modify the preset parameter
Specifications:
Sensor | Electrochemical |
Detection gases | Phosphine (PH3) |
Detecting range | 0-20ppm |
Alarm level | 5ppm and 10ppm or Customerized |
Resolution | 0.1ppm |
Time display | Year, month, day, and clock display function |
Alarm ways | voice alarm More than 90 dB (10cm away from instrument), light alarm |
Work mode | continuous work |
Temperature | - 20 ℃ ~ 50 ℃ |
Humidity | 15% ~ 95% RH (No condensation) |
Power supply | lithium battery power supply (1800 mAh) |
Charging time | 3 ~ 5 hours |
Working time | 12h without alarm |
Charging voltage | DC5V |
Model | Range | Resolution | L-alarm | H-alarm |
CO | 0-1000ppm | 1ppm | 50ppm | 150ppm |
O2 | 0-30%vol | 0.1%vol | 19.5%vol | 23.5%vol |
H2 | 0-1000ppm | 1ppm | 50ppm | 150ppm |
H2S | 0-100ppm | 0.1ppm | 10ppm | 20ppm |
CH4 | 0-100%LEL | 1%lel | 20%LEL | 50%LEL |
C2H4O | 0-100ppm | 1/0.1ppm | 20ppm | 50ppm |
EX | 0-100%LEL | 1%lel/1%vol | 20%LEL | 50%LEL |
C3H8 | 0-100%LEL | 1%lel/1%vol | 20%LEL | 50%LEL |
C2H5OH | 0-100%LEL | 1%lel/1%vol | 20%LEL | 50%LEL |
NH3 | 0-100ppm | 0.1/1ppm | 20ppm | 50ppm |
CL2 | 0-20ppm | 0.1ppm | 5ppm | 10ppm |
O3 | 0-10ppm | 0.1ppm | 2ppm | 5ppm |
SO2 | 0-20ppm | 0.1/1ppm | 5ppm | 10ppm |
PH3 | 0-20ppm | 0.1ppm | 5ppm | 10ppm |
CO2 | 0-5000ppm | 1ppm/0.1%vol | 1000ppm | 2000ppm |
NO | 0-250ppm | 1ppm | 50ppm | 150ppm |
NO2 | 0-20ppm | 0.1ppm | 5ppm | 10ppm |
HCN | 0-50ppm | 0.1/0.01ppm | 10ppm | 20ppm |
HCL | 0-20ppm | 0.001/0.1ppm | 5ppm | 10ppm |
CH2O | 0-20ppm | 1/0.1ppm | 5ppm | 10ppm |
HF | 0-100ppm | 0.01/0.1ppm | 2ppm | 5ppm |
C7H8/C8H10 | 0-20ppm | 0.01/0.1ppm | 5ppm | 10ppm |
